Description

Ideal for mission critical fiber optic ring networks, the TC3820 Redundant Ring Gigabit Ethernet Switch provides maximum reliability through its sophisticated redundant ring technology. If a fiber cable or device failure occurs, the data path automatically switches over within 250 msec. to the secondary path to maintain Ring network integrity.Available with SNMP Management, the Model TC3820 1000Base-SX/LX Switch provides six 10/100M copper ports and two Gigabit fiber ports. It can be daisy-chained and supports distances between switches up to 100 km.

The Ring can be single mode or multimode fiber (1300/1550nm) or CAT5 UTP cables. The TC3820 is IEEE 802.3, 802.3u, 802.3x and 802.z compliant.Industrial Hardened, Rugged or Outdoor versions are available for harsh environments (e.g. Process Control applications in Manufacturing, Utility, SCADA, Transportation, & Traffic Control). These versions exceed all pertinent Utility and Traffic Control environmental and temperature specifications (-40°C to 80°C).A Web-based configuration user interface is provided to view and change network settings such as IP Address, Subnet, Gateway, Speed, Half/Full Duplex, Name, Password and other parameters. It also monitors the fiber ring status, alarm conditions, fault locations for local and remote units. The TC3820 can also be configured through a serial console (Out-of-Band).

The TC3820's store-forward switching technology eliminates the congestion problem inherent to the contention-oriented Ethernet CSMA/CD protocol.Power is 12VDC, optional 24Vdc, -48Vdc, 125Vdc or 115/230VAC. Power redundancy is standard on 12Vdc. The unit is 19" rack mountable. Optical connectors can be ST, FC or SC

FEATURES

Ring Self-Heals within 250ms
Network Management (SNMP, Web, Telnet)
IEEE 802.3, 802.3u, 802.3x Compliant
6 Ethernet 10/100-Base Auto-Sensing UTP Ports
2 Fiber Optic 1000Base-SX/LX Ports
Standard Single Mode Distance of 50km (optional 100km)
Multimode or Single Mode (1300/1550nm)
Full or Half-Duplex Operation
Industrial Hardened (optional)
Hi-Temp2 Version Exceeds NEMA & Caltrans Traffic Control Specs
12VDC, Optional 24VDC, -48VDC, 125VDC or 115/230VAC

Because it functions like an Ethernet bridge (connects multiple Ethernet segments to prevent unnecessary network traffic), it creates an efficient sub-divided switched LAN that provides full and transparent bandwidth for each segment.

The TC3705's modern switching technology eliminates the congestion problem inherent to the contention-oriented Ethernet CSMA/CD protocol. This improves predictable response times under heavy network loads. Previously, expensive routing technology was used to alleviate congestion from heavy traffic loads.Power is 12VDC, optional 24Vdc, -48Vdc, 125Vdc or 115/230VAC with an external power cube. The TC3705S is the standalone/wallmount unit. The TC3705R rackmount version fits into the TCRM192 or TCRM196 19" rackmount card cages. Optical connectors can be SC, ST or FC.



Technical Specifications

Data Rates
10/100 Mbps (electrical)
1000 Mbps (optical)
Optical
Interface 2 Ethernet 1000Base-SX,-LX
Transmitter ELED, LASER
Receiver PIN Diode
Wavelength 1300nm Multimode
1300nm, 1550nm Single Mode
Fiber Optic Connectors ST, optional FC or SC
Loss Budget*
(1300nm, 1550nm)
Multimode (62.5/125µm): 15dB
Single Mode (9/125µm): 20dB
Laser Single Mode: 25dB
Electrical
Ethernet Ports 6 RJ-45 Female
Interface Ethernet 10/100Base-T (auto-sensing)
Standard IEEE 802.3/3u/3x
Bit Error Rate 1 in 10^9 or better
System
Bit Error Rate 1 in 10^9 or better
Fault Recovery < 250 msec.
Visual Indicators
System Status Power, Status (8)
Port Status (Each Port) 10/100, Act, Link, Tx, Rx, Speed
Alarm
Dry Contact Normal OPEN
Power
Standard 12VDC @ 500mA
Optional 24VDC, -48VDC, 125VDC or 115/230VAC (with external power cube)
Temperature
Operating -10° to 50°C
High Temp (Optional) -20° to 70°C
Hardened (Optional) -40° to 80°C
Storage -40° to 90°C
Humidity 95% non-condensing
Physical (Rackmount Unit)
Height (3.53 cm) 1.75"
Width (48.26 cm) 19.0"
Depth (16.57 cm) 6.5"
Weight (544 gm) 1.2 lbs
