Wholesale
CAT 6 Cable- CAT 6 Cable
We Stock CAT 6 Plenum Cable- 550 MHZ Everyday
for $ 259/1000 Feet -PALLET QUANTITY ONLY
This is our wholesale
CAT 6 Cable Division Pricing Only for contractors-OEMS- Project
Prices- Special Pricing Only Available in 250 Box (plus ) quantity
purchases.
CAT 6 PLENUM CABLE $259/1000 Feet- for minumum
5 pallet quantities
American Data Supply now has one of the largest supplies
and selections of CAT 6 Cable-CAT 6 patch cords and CAT 6 patch
cables- Due to rapidly fluctuating market prices on commodities
such as oil- copper- etc that make up CAT 5e Cable and CAT 6 cable.
CAT
6 PVC CABLE $110/ 1000 Feet - for minumum
5 pallet quantities
American Data Supply also offer tremendous DISCOUNTS and will MEET or BEAT any USA based pricing for BULK CAT 5e and CAT 6 Cables- Please call us at (866) 342-3721 for pallet pricing with cable prices as low as $ 125/1000 feet.
CAT
6 CABLE DESCRIPTION |
Part
Number |
Description-
Specifications |
STANDARD
PRICING |
CAT6 Cable |
K6-1KSTP-BL |
CAT6 550MHz Cable, 24AWG, STP, 4 Pairs,
1000', Blue |
$ 169.00/1000 Feet -ALL COLORS |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-BK |
CAT-6 550MHz Cable, 23AWG, UTP, 4 Pairs,
Solid, Plenum, 1000', Black-Plenum Rated CAT6E Bulk Cable,
CMP, UTP, Solid, 1000ft box, Bulk |
$ 399.00 /1000 Feet -plenum |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-BL |
CAT-6 550MHz Cable, 23AWG, UTP, 4 Pairs,
Solid, Plenum, 1000', Blue-Plenum Rated CAT6E Bulk Cable,
CMP, UTP, Solid, 1000ft box, Bulk |
$ 399.00 /1000 Feet-plenum |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-GR |
CAT-6 550MHz Cable, 23AWG, UTP, 4 Pairs,
Solid, Plenum, 1000', Green-Plenum Rated CAT6E Bulk Cable,
CMP, UTP, Solid, 1000ft box, Bulk |
$ 399.00 /1000 Feet-plenum |
CAT6 Cable |
K6-1KSTP-BL |
CAT6 550MHz Cable, 24AWG, STP, 4 Pairs,
1000', Blue |
$ 169.00/1000 Feet- ALL COLORS |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-BK |
CAT-6 550MHz Cable, 23AWG, UTP, 4 Pairs,
Solid, Plenum, 1000', Black-Plenum Rated CAT6E Bulk Cable,
CMP, UTP, Solid, 1000ft box, Bulk |
$ 399.00 /1000 Feet-plenum |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-BL |
CAT-6 550MHz Cable, 23AWG, UTP, 4 Pairs,
Solid, Plenum, 1000', Blue-Plenum Rated CAT6E Bulk Cable,
CMP, UTP, Solid, 1000ft box, Bulk |
$ 399.00 /1000 Feet-plenum |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-GR |
CAT-6 550MHz Cable, 23AWG, UTP, 4 Pairs,
Solid, Plenum, 1000', Green-Plenum Rated CAT6E Bulk Cable,
CMP, UTP, Solid, 1000ft box, Bulk- |
$ 399.00/1000 Feet-plenum |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-GY |
CAT-6 550MHz Cable, 23AWG, UTP, 4 Pairs,
Solid, Plenum, 1000', Gray-Plenum Rated CAT6E Bulk Cable,
CMP, UTP, Solid, 1000ft box, Bulk |
$ 399.00 /1000 Feet-plenum |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-RD |
CAT-6 550MHz Cable, 23AWG, UTP, 4 Pairs,
Solid, Plenum, 1000', Red-Plenum Rated CAT6E Bulk Cable, CMP,
UTP, Solid, 1000ft box, Bulk |
$ 399.00 /1000 Feet-plenum |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-WH |
CAT-6
550MHz Cable, 23AWG, UTP, 4 Pairs, Solid, Plenum, 1000', White-Plenum
Rated CAT6E Bulk Cable, CMP, UTP, Solid, 1000ft box, Bulk |
$ 399.00 /1000 Feet-plenum |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-YL |
CAT-6
550MHz Cable, 23AWG, UTP, 4 Pairs, Solid, Plenum, 1000', Yellow
-Plenum Rated CAT6E Bulk Cable, CMP, UTP, Solid, 1000ft box,
Bulk |
$ 399.00 /1000 Feet-plenum |
2`re q2
550 MHZ CAT 6 CABLE - Available
in CAT 6 Plenum and CAT
6 PVC
CAT6 Bulk
Cable- CAT 6 Plenum and CAT 6 PVC Cable Specifications Below THE
BELOW PRICES ARE TYPICAL SUGGESTED PRICES- DUE TO THE PRICE OF
OIL&
COPPER
THE PRICES CAN FLUCTUATE DAILY- CALL (866) 342-3721 FOR UP TO
DATE PRICING
"WE
HAVE MOST CAT 6 PATCH CORDS IN STOCK & CAN SHIP
THE VERY SAME DAY"
1000
Foot Rolls of CAT 6 PVC as Low as $ 125.00/1000 Foot Rolls- Call
For Details- Minimum's Required! (866) 342-3721 or 650-DATA
American Data Supply offers a wide variety of CAT 6 cable including our wholesale cat 6 cable including CAT 6 cable UTP twisted pair cables ranging from CAT 6 Plenum cable, CAT 6 Cable from Commscope's 5504M, Belden's Media Twist and Helix Hi Temps's equivalent's CAT 6 enhanced cables.We also have a full range of PVC CAT 6 rated cables, CAT 5e, outdoor rated CAT 5e cable, CAT 6, and CAT 6 Plenum enhanced, Smart Cable, and indoor/outdoor rated cable to suit your needs from several manufacturers. CommScope's CAT 6 cable offers unshielded twisted pair cable technology that is designed to serve the high speed local area network marketplace. CommScope's Network products are among the highest performing twisted pair products on the market. We have great pricing on Category 6 Enhanced -CAT 6 Cable equivalent to the Belden 7852A Cable for about 40% less.
American Data Supply Carries CAT6 CABLE BULK CABLE
FROM THE BELOW MANUFACTURERS AS WELL AS OTHERS
We
carry CAT6 PVC and CAT 6 Plenum cable from Belden, Berktek, Commscope,
Essex, General, AMP, Mohawk, Systimax and more.
Category
6 (CAT 6) technology is rapidly growing in the telecommunications
industry’s commercial market. CAT 6 has been under development
since late 1997. Originally, the wiring was intended to go from
the 100 MHz capability of CAT 5 to 200 MHz, but later that was
revised to 250 MHz. CAT 6 provides for other metrics as well,
variables that become important at high bandwidth rates. These
include crosstalk, or interference between wire pairs, and skew,
the difference in timing of signals on the wires.
CAT 6 is the latest type
of four pair twisted copper cable designed for high speed data
transmission. CAT 5 was initially touted as the last cable you'll
ever need, but then came Gigabit Ethernet, which pushed the technology
to its limits and used all four pairs of wires in the cable. So,
manufacturers started making, "enhanced", versions of the cable
(hence the "E”). Bandwidth precedes data rates just as highways
come before traffic. Doubling the bandwidth is like adding twice
the number of lanes on a highway. The trends of the past and the
predictions for the future indicate that data rates have been
doubling every 18 months. Current applications running at 1 Gb/s
are really pushing the limits of Category 5E cabling. As streaming
media applications such as video and multi-media become increasingly
commonplace, the demands for faster data rates will increase and
spawn new applications that will benefit from the higher bandwidth
offered by Category 6. This is exactly what happened in the early
’90s when the higher bandwidth of Category 5 cabling compared
to Category 3 caused most local area network (LAN) applications
to choose the better media to allow simpler, cost effective, higher
speed LAN applications, such as 100BASE-TX. It is also important
to note that cabling infrastructure is generally considered a
10 year investment as opposed to one or three years for electronics
or software.
CAT
6 CABLE DESCRIPTION |
Part
Number |
Description-
Specifications |
PRICE |
CAT6 Cable |
K6-1KSTP-BL |
CAT6 550MHz Cable, 24AWG,
STP, 4 Pairs, 1000', Blue |
$ 169.00/1000 Feet |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-BK |
CAT-6 550MHz Cable,
23AWG, UTP, 4 Pairs, Solid, Plenum, 1000', Black |
$ 399.00 /1000 Feet-plenum |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-BL |
CAT-6 550MHz Cable,
23AWG, UTP, 4 Pairs, Solid, Plenum, 1000', Blue |
$ 399.00 /1000 Feet-plenum |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-GR |
CAT-6 550MHz Cable,
23AWG, UTP, 4 Pairs, Solid, Plenum, 1000', Green |
$ 399.00/1000 Feet-plenum |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-GY |
CAT-6 550MHz Cable,
23AWG, UTP, 4 Pairs, Solid, Plenum, 1000', Gray |
$ 399.00 /1000 Feet-plenum |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-RD |
CAT-6 550MHz Cable,
23AWG, UTP, 4 Pairs, Solid, Plenum, 1000', Red |
$ 399.00 /1000 Feet-plenum |
CAT6 Plenum Cable |
K6-1KUTP-PLEN-WH |
CAT-6 550MHz Cable,
23AWG, UTP, 4 Pairs, Solid, Plenum, 1000', White |
$ 399.00 /1000 Feet-plenum |
CAT6 PVC Cable |
K6-1KUTP-BL |
CAT-6 550MHz Cable, 23AWG, UTP,
4 Pairs, Solid, 1000', Blue |
$ 169.00/1000 Feet |
CAT6 PVC
Cable |
K6-1KUTP-WH |
CAT-6 550MHz Cable,
23AWG, UTP, 4 Pairs, Solid, 1000', White |
$ 169.00/1000 Feet |
CAT6 PVC
Cable |
K6-1KUTP-RD |
CAT-6 550MHz Cable,
23AWG, UTP, 4 Pairs, Solid, 1000', Red |
$ 169.00/1000 Feet |
CAT6 PVC
Cable |
K6-1KUTP-GR |
CAT-6 550MHz Cable,
23AWG, UTP, 4 Pairs, Solid, 1000', Green |
$ 169.00/1000 Feet |
CAT6 Cable
|
K6-1KUTP-GY |
CAT-6 550MHzCable, 23AWG,
UTP, 4 Pairs, Solid, 1000', Gray |
$ 169.00/1000 Feet |
CAT6 Cable
|
K6-1KUTP-YL |
CAT-6 550MHz Cable,
23AWG, UTP, 4 Pairs, Solid, 1000', Yellow |
$ 169.00/1000 Feet |
CAT6 Cable |
K6-1KUTP-BL/ST |
CAT-6 550MHz Cable, 24AWG, UTP,
4 Pairs, Stranded, 1000', Blue |
$ 169.00/1000 Feet |
CAT6 Cable |
K6-1KUTP-GY/ST |
CAT-6 550MHz Cable, 24AWG, UTP,
4 Pairs, Stranded, 1000', Gray |
$ 169.00/1000 Feet |
CAT6 Cable |
K6-1KUTP-RD/ST |
CAT-6 550MHz Cable, 24AWG, UTP,
4 Pairs, Stranded, 1000', Red |
$ 169.00/1000 Feet |
CAT6 Cable |
K6-1KUTP-GR/ST |
CAT-6 550MHz Cable, 24AWG, UTP,
4 Pairs, Stranded, 1000', Green |
$ 169.00/1000 Feet |
CAT6 Cable |
K6-1KUTP-WH/ST |
CAT-6 550MHz Cable, 24AWG, UTP,
4 Pairs, Stranded, 1000', White |
$ 169.00/1000 Feet |
CAT6 Cable |
K6-1KUTP-YL/ST |
CAT-6 550MHz Cable, 24AWG, UTP,
4 Pairs, Stranded, 1000', Yellow |
$ 169.00/1000 Feet |
|
|
-
-
Suitable for 550MHz High-Speed Transmission
-
Suitable for Indoor Installations
-
Ultra-High-Performance Data Communications Cable
-
Booted, snagless cords smoothly connect hubs, patch panels, wall outlets and workstations
-
Boots offer cable-end color ID, strain relief and RJ45 plug tab protection from snagging on cables or connectors when routing in ceilings and under floors
-
Critical Network Applications, Gigabit Ethernet, Fast Ethernet, Broadband Audio and Video, 155Mbps ATM, 100Mbps TP-PMD/CDDI, NEXT, ELFEXT and RL Bandwidth Compliant
|
- 4-Pair AWG23-Stranded Copper UTP Cable
- 100% Tested Wiring Sequence and Continuity
- Terminated to 8-Contact RJ45 Modular Plugs
- 50µ˝ Hard-Gold Plating Over 80µ˝ Nickel
- Excellent Attenuation and Crosstalk Characteristics
- Impedance 100Ω±15% – DC Resistance 23Ω/1000ft
- Mutual Capacitance 14pF/ft Maximum @ 1kHz
- Velocity of Propagation 68%
- PVC Jacket
- Flame Retardant – Type CM CMH, CMR
- Exceeds Category-6 ANSI/TIA/EIA 568B.2-1 and ISO/IEC 11801 standards and all proposed Category-6 requirements for high-speed, full duplex, parallel transmission protocols
- UL/UL and ETL Listed
Category:
Voice and Data
Type: CAT6 Patch Cords - Molded w/ Protector |
|
Part Number |
|
Price |
ATSK6-UMP-1-BK-01-or
576-100-001 |
CAT
6 550MHz, Patch Cord, Molded W/Boot &
Bubble, 1 Foot, Black |
CAT 6 Booted Patch Cords |
$ 1.10 each |
ATSK6-UMP-1-BL-03
576-100-003 |
CAT
6 550MHz, Patch Cord, Molded W/Boot &
Bubble,3 Foot Blue |
CAT 6 Booted Patch Cords |
$ 1.79 each |
ATSK6-UMP-1-GR-05 -or
576-100-005 |
CAT
6 550MHz, Patch Cord, Molded W/Boot &
Bubble, 5 Foot, Green |
CAT 6 Booted Patch Cords |
$2.19 each |
ATSK6-UMP-1-GY-07-or
576-100-007 |
CAT
6 550MHz, Patch Cord, Molded W/Boot &
Bubble, 7 Foot, Gray |
CAT 6 Booted Patch Cords |
$ 2.69 each |
ATSK6-UMP-1-OR -or
576-100-010
|
CAT6
550 MHz, Patch Cord Molded W/Boot &
Bubble, 10 Foot, Orange |
CAT 6 Booted Patch Cords |
$ 3.39 each |
ATSK6-UMP-1-RD-14 or
576-100-014 |
CAT
6 550MHz, Patch Cord, Molded W/Boot &
Bubble, 14 Foot, Red |
CAT 6 Booted Patch Cords |
$ 3.89 each |
ATSK6-UMP-1-WH-15- or
576-100-015 |
CAT
6 550MHz, Patch Cord, Molded W/Boot &
Bubble, 15 Foot White |
CAT 6 Booted Patch Cords |
$3.99 each |
ATSK6-UMP-1-YL-25- or
576-100-025 |
CAT
6 550MHz, Patch Cord, Molded W/Boot &
Bubble, 25 Foot, Yellow |
CAT 6 Booted Patch Cords |
$ 6.29 each |
ATSK6-UMP-10-BK-50 or
576-100-050 |
CAT
6 550MHz, Patch Cord, Molded W/Boot &
Bubble, 50 Foot, Black |
CAT 6 Booted Patch Cords |
$ 7.69 each |
ATSK6-UMP-10-BL-100 or
576-100-100 |
CAT
6 550MHz, Patch Cord, Molded W/Boot &
Bubble, 100 Foot, Blue |
CAT 6 Booted Patch Cords |
$ 12.59 each |
CAT 6 Shielded Patch Cords
Part Number |
|
|
ATS100806BK- Available in 1 foot-2Foot-3Foot-5Foot-7Foot-10Foot- 15Foot- 25Foot- 50 Foot-75 Foot-100 Foot- 150 Foot Lengths |
Shielded CAT 6 550MHz, Patch Cord, Molded W/Boot & Bubble, 1 Foot, Black |
* TIA/EIA 568A T568B Wired
* STP Shielded Twist Pair
* Foil Shield on individual Pair/Braid shield on 4 pair
* CM Type PVC Jacket
* 26AWG 4pair Stranded Copper Wire
* 50 Micron Gold Plated RJ45 Plug
* Molded Boot on Each End
* Cable Length marked on Boot |
|
ATS100806BL
1 foot-2Foot-3Foot-5Foot-7Foot-10Foot- 15Foot- 25Foot- 50 Foot-75 Foot-100 Foot- 150 Foot Length |
Shielded CAT 6 550MHz, Patch Cord, Molded W/Boot & Bubble, 1 Foot, Blue |
* TIA/EIA 568A T568B Wired
* STP Shielded Twist Pair
* Foil Shield on individual Pair/Braid shield on 4 pair
* CM Type PVC Jacket
* 26AWG 4pair Stranded Copper Wire
* 50 Micron Gold Plated RJ45 Plug
* Molded Boot on Each End
* Cable Length marked on Boot |
|
ATS100806GN in 1 foot-2Foot-3Foot-5Foot-7Foot-10Foot- 15Foot- 25Foot- 50 Foot-75 Foot-100 Foot- 150 Foot Length |
Shielded CAT 6 550MHz, Patch Cord, Molded W/Boot & Bubble, 1 Foot, Green |
* TIA/EIA 568A T568B Wired
* STP Shielded Twist Pair
* Foil Shield on individual Pair/Braid shield on 4 pair
* CM Type PVC Jacket
* 26AWG 4pair Stranded Copper Wire
* 50 Micron Gold Plated RJ45 Plug
* Molded Boot on Each End
* Cable Length marked on Boot |
|
ATS100806OR in 1 foot-2Foot-3Foot-5Foot-7Foot-10Foot- 15Foot- 25Foot- 50 Foot-75 Foot-100 Foot- 150 Foot Length |
Shielded CAT 6 550MHz, Patch Cord, Molded W/Boot & Bubble, 1 Foot, Gray |
* TIA/EIA 568A T568B Wired
* STP Shielded Twist Pair
* Foil Shield on individual Pair/Braid shield on 4 pair
* CM Type PVC Jacket
* 26AWG 4pair Stranded Copper Wire
* 50 Micron Gold Plated RJ45 Plug
* Molded Boot on Each End
* Cable Length marked on Boot |
|
ATS100806RD in 1 foot-2Foot-3Foot-5Foot-7Foot-10Foot- 15Foot- 25Foot- 50 Foot-75 Foot-100 Foot- 150 Foot Length |
ShieldedCAT6 550 MHz, Patch Cord Molded W/Boot, 1 Foot, Orange |
* TIA/EIA 568A T568B Wired
* STP Shielded Twist Pair
* Foil Shield on individual Pair/Braid shield on 4 pair
* CM Type PVC Jacket
* 26AWG 4pair Stranded Copper Wire
* 50 Micron Gold Plated RJ45 Plug
* Molded Boot on Each End
* Cable Length marked on Boot |
|
ATS100806WT in 1 foot-2Foot-3Foot-5Foot-7Foot-10Foot- 15Foot- 25Foot- 50 Foot-75 Foot-100 Foot- 150 Foot Length |
ShieldedCAT 6 550MHz, Patch Cord, Molded W/Boot, 1 Foot, Red |
* TIA/EIA 568A T568B Wired
* STP Shielded Twist Pair
* Foil Shield on individual Pair/Braid shield on 4 pair
* CM Type PVC Jacket
* 26AWG 4pair Stranded Copper Wire
* 50 Micron Gold Plated RJ45 Plug
* Molded Boot on Each End
* Cable Length marked on Boot |
|
ATS100806YW in 1 foot-2Foot-3Foot-5Foot-7Foot-10Foot- 15Foot- 25Foot- 50 Foot-75 Foot-100 Foot- 150 Foot Length |
Shielded CAT 6 550MHz, Patch Cord, Molded W/Boot , 1 Foot, White |
* TIA/EIA 568A T568B Wired
* STP Shielded Twist Pair
* Foil Shield on individual Pair/Braid shield on 4 pair
* CM Type PVC Jacket
* 26AWG 4pair Stranded Copper Wire
* 50 Micron Gold Plated RJ45 Plug
* Molded Boot on Each End
* Cable Length marked on Boot |
|
CAT 6 Outdoor Rated Cable -Standard-Part
Number: ATSCAT6-OSP CAT6
250MHz, Cable, 24AWG, UTP, 4 Pairs, Solid, 1000', UV Jacket for
Outdoor Use, (CMX) Cable, Black -
SEE SPECIFICATIONS
Part Number: ATSCAT6-OSP Cost $ 299.00 /1000 FT- Volume discounts apply to as low as $ 239/1000 fe2t in quantities 25+- please call first for details as American Data Supply is not responsible for rapid changes due to oil/copper costs
Volume
Price $ 259.00 - Ten (10) or more Boxes
Outdoor Rated -Outdoor Shielded CAT 5e and CAT 6 Patch Cords
Outdoor
Rated CAT 6 Patch Cords Cat6
cable specifications require stagger terminated wiring, as shown
at the left. Cat 6 Shielded Cable is used in network applications
such as 10Base-T, 100Base-T, 1000Base-T Ethernet technology to 100
meters (328 feet), and have been designed specifically for Gigabit
Ethernet applications (Gigabit over copper). They perform at high-data
transfer rates, and work with ATM and gigabit speed products. These
cables deliver improved performance over standard Cat5e cables.
Cat 6 is completely backward-compatible with current Cat5e equipment.
Our Cat 6 Cables are composed of 4 pairs 24 AWG stranded conductors
with PVC jackets. Conductors are wired to gold plated RJ45 plugs
in accordance with the TIA/EIA 568B standard (Telephone Industry
Association/Electronics Industry Association.) They consist of
a foil shield with drain wire to protect signals from external
noise. Available in nine colors. Boots match cable color. Custom
modular cable assemblies are available.
Part
Number |
Outdoor
Rated CAT 6 Patch Cords |
|
|
560-125-050-OSP-C6 |
50
Foot Outdoor Rated CAT 6Patch Cables |
|
|
560-125-100-OSP-C6 |
100
Foot Outdoor Rated CAT 6 Patch Cables |
|
$ 69.60 |
560-125-125-OSP-C6 |
125
Foot Outdoor Rated CAT 6Patch Cables |
|
$ 72.00 |
560-125-150-OSP-C6 |
150
Foot Outdoor Rated CAT 6 Patch Cables |
|
$ 104.40 |
560-125-175-OSP-C6 |
175Foot
Outdoor Rated CAT 6 Patch Cables |
|
$ 127.60 |
560-125-200-OSP-C6 |
200
Foot Outdoor Rated CAT 6 Patch Cables |
|
$ 156.60 |
560-125-225-OSP-C6 |
225
Foot Outdoor Rated CAT 6 Patch Cables |
|
$ 171.10 |
560-125-250-OSP-C6 |
250Foot
Outdoor Rated CAT 6 Patch Cables |
|
$ 185.60 |
560-125-275-OSP-C6 |
275
Foot Outdoor Rated CAT 6 Patch Cables |
|
|
Custom
Lengths-Call |
Custom Outdoor Patch
Cords- Call |
Black |
CALL |
550 MHZ CAT 6 Cable- Avaialable in CAT 6 Plenum and CAT 6 PVC
CAT6 Bulk Cable- CAT 6 Plenum and CAT 6 PVC Cable Specifications Below |
|
Type |
Part
Number |
Description |
CAT6 Cable |
K6-1KSTP-BL |
CAT6 550MHz Cable, 24AWG, STP, 4 Pairs,
1000', Blue |
Plenum CAT6 Cable |
K6-1KUTP-PLEN-BK |
Black Plenum CAT-6 550MHz Cable, 23AWG,
UTP, 4 Pairs, Solid, Plenum, 1000', Black |
Plenum CAT6 Cable |
K6-1KUTP-PLEN-BL |
Blue Plenum CAT-6 550MHz Cable, 23AWG,
UTP, 4 Pairs, Solid, Plenum, 1000', Blue |
Plenum CAT6 Cable |
K6-1KUTP-PLEN-GR |
Green Plenum CAT-6 550MHz Cable, 23AWG,
UTP, 4 Pairs, Solid, Plenum, 1000', Green |
Plenum CAT6 Cable |
K6-1KUTP-PLEN-GY |
Gray Plenum CAT-6 550MHz Cable, 23AWG,
UTP, 4 Pairs, Solid, Plenum, 1000', Gray |
Plenum CAT6 Cable |
K6-1KUTP-PLEN-RD |
Red Plenum CAT-6 550MHz Cable, 23AWG,
UTP, 4 Pairs, Solid, Plenum, 1000', Red |
Plenum CAT6 Cable |
K6-1KUTP-PLEN-WH |
White Plenum CAT-6 550MHz Cable, 23AWG,
UTP, 4 Pairs, Solid, Plenum, 1000', White |
CAT6 Cable |
K6-1KUTP-BL |
CAT-6 550MHz Cable, 23AWG, UTP, 4 Pairs, Solid,
1000', Blue |
CAT6 Cable |
K6-1KUTP-WH |
CAT-6 550MHz Cable, 23AWG, UTP, 4
Pairs, Solid, 1000', White |
CAT6 Cable |
K6-1KUTP-RD |
CAT-6 550MHz Cable, 23AWG, UTP, 4
Pairs, Solid, 1000', Red |
CAT6 Cable |
K6-1KUTP-GR |
CAT-6 550MHz Cable, 23AWG, UTP, 4
Pairs, Solid, 1000', Green |
CAT6 Cable |
K6-1KUTP-GY |
CAT-6 550MHzCable, 23AWG, UTP, 4 Pairs,
Solid, 1000', Gray |
CAT6 Cable |
K6-1KUTP-YL |
CAT-6 550MHz Cable, 23AWG, UTP, 4
Pairs, Solid, 1000', Yellow |
CAT6 Cable |
K6-1KUTP-BL/ST |
CAT-6 550MHz Cable, 24AWG, UTP, 4 Pairs, Stranded,
1000', Blue |
CAT6 Cable |
K6-1KUTP-GY/ST |
CAT-6 550MHz Cable, 24AWG, UTP, 4 Pairs, Stranded,
1000', Gray |
CAT6 Cable |
K6-1KUTP-RD/ST |
CAT-6 550MHz Cable, 24AWG, UTP, 4 Pairs, Stranded,
1000', Red |
CAT6 Cable |
K6-1KUTP-GR/ST |
CAT-6 550MHz Cable, 24AWG, UTP, 4 Pairs, Stranded,
1000', Green |
CAT6 Cable |
K6-1KUTP-WH/ST |
CAT-6 550MHz Cable, 24AWG, UTP, 4 Pairs, Stranded,
1000', White |
CAT6 Cable |
K6-1KUTP-YL/ST |
CAT-6 550MHz Cable, 24AWG, UTP, 4 Pairs, Stranded,
1000', Yellow |
Plenum CAT6 Cable |
K6-1KUTP-PLEN-YL |
Yellow Plenum CAT-6 550MHz Cable, 23AWG, UTP,
4 Pairs, Solid, Plenum, 1000', White |
|
CAT
3-CAT 3 LAN Cable Composite
Cable
Our outdoor rated CAT
5e cable is available in 500 foot- 1000 foot reels as well as
custom lengths- since the outdoor rated CAT 5e cable is based
on the cost of oil-you need to call us at (866) 342-3721 to get
the latest pricing. Generally the outdoor rated CAT 5e Cable costs
from$ 150-$ 195 per 1000 foot reel. With custom lengths of the
outdoor rated CAT 5e cable there is also a cut charge. We normally
ship the same day if order is placed before
1pm PST.
CAT 5e- Cat 6- CAT 6 Cable Tutorial
Category 5 Cable (UTP) (Unshielded Twisted Pair) |
A multipair (usually 4 pair) high performance cable that consists of twisted pair conductors, used mainly for data transmission. Note: The twisting of the pairs gives the cable a certain amount of immunity from the infiltration of unwanted interference. category-5 UTP cabling systems are by far, the most common (compared to SCTP) in the United States. Basic cat 5 cable was designed for characteristics of up to 100 MHz. Category 5 cable is typically used for Ethernet networks running at 10 or 100 Mbps. |
Category 5 E Cable (enhanced) |
Same as Category 5, except that it is made to somewhat more stringent standards. The Category 5 E standard is now officially part of the 568A standard. Category 5 E is recommended for all new installations, and was designed for transmission speeds of up to 1 gigabit per second (Gigabit Ethernet). |
Category 6 |
Same as Category 5 E, except that it is made to a higher standard. The Category 6 standard is now officially part of the 568A standard. |
Category 7 |
Same as Category 6, except that it is made to a higher standard. The Category 7 standard is still in the works (as of this writing) and is not yet part of the 568A standard. One major difference with category 7's construction (as compared with category 5, 5 E, and 6) is that all 4 pairs are individually shielded, and an overall shield enwraps all four pairs. Category 7 will use an entirely new connector (other than the familiar RJ-45). |
Category 5 Cable (SCTP) (Screened Twisted Pair) |
Same as above, except that the twisted pairs are given additional protection from unwanted interference by an overall shield. There is some controversy concerning which is the better system (UTP or SCTP). Category 5 SCTP cabling systems require all components to maintain the shield, and are used almost exclusively in European countries. |
Category 5E, RJ45 jack
(Work Area Outlet) |
An 8 conductor, compact, modular, female jack that is used to terminate category-5E cable at the user (or other) location. The jack is specifically engineered to maintain the performance of cat 5E cabling. |
Category 5E Patch Panel |
A Category 5E Patch Panel is basically just a series of many category-5E jacks, condensed onto a single panel. Common panel configurations are 12, 24, 48, and 96 ports. Patch panels are typically used where all of the horizontal cable sections meet, and are used to connect the segments to the Network Hub. |
Category 5E Patch Cable |
A Category 5E Patch Cable consists a length of cat 5E cable with an RJ-45 male connector, crimped onto each end. The cable assembly is used to provide connectivity between any two category-5E female outlets (jacks). The two most common are from hub to patch panel, and work area outlet (jack) to the computer. |
EIA/TIA 568A Standard |
This standard was published in July of 1991. The purpose of EIA/TIA 568A, was to create a multiproduct, multivendor, standard for connectivity. Prior to the adoption of this standard, many "proprietary" cabling systems existed. This was very bad for the consumer. Among other things, the standard set the minimum requirements for category 5E cable and hardware. The 568 "standard" is not to be confused with 568A or 568B wiring schemes, which are themselves, part of the "568A standard". |
568A and 568B Wiring Schemes |
When we refer to a jack or a patch panel's wiring connection, we refer to either the 568A, or 568B wiring scheme, which dictates the pin assignments to the pairs of cat 5E cable. It is very important to note that there is no difference, whatsoever, between the two wiring schemes, in connectivity or performance when connected form one modular device to another (jack to Patch panel, RJ-45 to RJ-45, etc.), so long as they (the two devices) are wired for the same scheme (A or B). The only time when one scheme has an advantage over the other, is when one end of a segment is connected to a modular device, and the other end to a punch block. In which case, the 568A has the advantage of having a more natural progression of pairs at the punch block side. More on 568 A&B later on. |
Four Pairs |
Pair 1: White / Blue |
Pair 3: White / Green |
Pair 2: White / Orange |
Pair 4: White / Brown |
|
Wiremap |
This is the most basic test that can be performed on a category-5E segment. Wiremap tests for the basic continuity between the two devices. In 568A or B, all eight pins of each device should be wired straight through (1 to 1, 2 to 2, 3 to 3, etc.). A wiremap (continuity) test, should also test for absence of shorts, grounding, and external voltage. |
Crosstalk |
Crosstalk is the "bleeding" of signals carried by one pair, onto another pair through the electrical process of induction (wires need not make contact, signals transferred magnetically). This is an unwanted effect, that can cause slow transfer, or completely inhibit the transfer of data signals over the cable segment. The purpose of the wire twists, in category 5E cable is to significantly reduce the crosstalk, and it's effects. Two types are: NEXT (Near End Crosstalk), and FEXT (Far End Crosstalk). Fiber Optic cable is the only medium that is 100% immune to the effects of crosstalk. |
Ambient Noise or Electromagnetic Interference (EMI) |
Similar to crosstalk, in that it is an unwanted signal that is induced into the cable. The difference is that ambient noise (or EMI) is typically induced from a source that is external to the cable. This could be an electrical cable or device, or even an adjacent category 5E cable. |
Attenuation |
Attenuation is the loss of signal in a cable segment due to the resistance of the wire plus other electrical factors that cause additional resistance (Impedance and Capacitance for example). A longer cable length, poor connections, bad insulation, a high level of crosstalk, or ambient noise, will all increase the total level of attenuation. The 568A standard, specifies the maximum amount of attenuation that is acceptable in a category-5E cable segment. |
So, when someone refers to 568A, are they talking about the standard, or the wiring scheme? The answer, is that it depends on the context. If they were to say "The entire office fully complies with 568A", obviously, they would be talking about the standard. If they were to say "The jacks and patch panels are all 568A", then they would be referring to the wiring scheme.
The 568 committee, with good intentions, decided to allow both wiring methods (568A & 568B) to exist within the 568A Standard. The reason was that at the time, a great deal of cabling plants had been installed to the B standard (formerly known as WECO or AT&T 258A). Even though they allowed both wiring methods, they stated in their standard that 568A wiring would be the preferred method for all new installations. Time, and popular opinion, went in the other direction. The most popular wiring method today is 568B. Having both A & B methods does nothing but cause errors and confusion. Originally, patch panels and jacks were manufactured either A or B. In most cases, they were not labeled as such. Most suppliers stocked only the B wired products. Luckily, today, almost all jacks and patch panels show diagrams for both A and B. The only difference between the two is the interchanging of the 2nd and 3rd pairs (white/orange and white/green, respectively).
So which method to choose? As we stated earlier; There is no difference, whatsoever, between the two wiring schemes, in connectivity or performance when connected form one modular device to another. The answer, is that it does not matter at all, unless you are terminating one end onto a punch block, in which case, the A method has an advantage. The main thing is that you choose one method, and stick with it. I recommend to all installers that they terminate one segment on both the jack and patch panel sides, and test for proper continuity. It has happened to many professionals, where they terminated the entire installation, and then discovered that the two ends were wired for different methods. Then they had to re-terminate all of the cables on one end completely to correct the situation.
The following charts should be very helpful in illustrating the difference between the A & B methods. For those who are not familiar with telephony, tip (T) refers to the positive (+) side, and ring (R) refers to the negative side of the circuit. The white/blue pair (the first pair in the cable) consists of two wires that are twisted together. They are the white/blue (tip) and the blue/white (ring). The white/blue wire is predominately white with a blue stripe. The blue/white is the inverse, predominately blue with a white stripe.
Category 5, 5 E, 6 and 7 Performance Specification Chart
Parameter |
Category 5
and Class D
with additional
requirements TSB95
and FDAM 2 |
Category 5E
('568-A-5) |
Category 6
Class E
(Performance at
250 MHz shown
in parentheses) |
Proposed
Category 7
Class F
(Performance at
600 MHz shown
in parentheses) |
Specified frequency range |
1-100 MHz |
1-100 MHz |
1-250 MHz |
1-600 MHz |
Attenuation |
24 dB |
24 dB |
21.7 dB
(36 dB) |
20.8 dB
(54.1 dB) |
NEXT |
27.1 dB |
30.1 dB |
39.9 dB
(33.1 dB) |
62.1 dB
(51 dB) |
Power-sum NEXT |
N/A* |
27.1 dB |
37.1 dB
(30.2 dB) |
59.1 dB
(48 dB) |
ACR |
3.1 dB |
6.1 dB |
18.2 dB
(-2.9 dB) |
41.3 dB
(-3.1 dB)** |
Power-sum ACR |
N/A |
3.1 dB |
15.4 dB
(-5.8 dB) |
38.3 dB
(-6.1 dB)** |
ELFEXT |
17 dB
(new requirement) |
17.4 dB |
23.2 dB
(15.3 dB) |
ffs*** |
Power-sum ELFEXT |
14.4 dB
(new requirement) |
14.4 dB |
20.2 dB
(12.3 dB) |
ffs*** |
Return loss |
8 dB*
(new requirement) |
10 dB |
12 dB
(8 dB) |
14.1 dB
(8.7 dB) |
Propagation delay |
548 nsec |
548 nsec |
548 nsec
(546 nsec) |
504 nsec
(501 nsec) |
Delay skew |
50 nsec |
50 nsec |
50 nsec |
20 nsec |
Note: Requirements for
Category 7 are currently under development.
Category 5E Bulk Cable
|
Type |
Part
Number |
Description |
CAT5E Plenum |
K5E-1KUTP-PLEN-RD |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Solid, Plenum, 1000', Red |
CAT5E Plenum |
K5E-1KUTP-PLEN-BL |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Solid, Plenum, 1000', Blue |
CAT5E Plenum |
K5E-1KUTP-PLEN-GY |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Solid, Plenum, 1000', Gray |
CAT5E Plenum |
K5E-1KUTP-PLEN-WH |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Solid, Plenum, 1000', White |
CAT5E Cable |
K5E-1KUTP-BL |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Solid, 1000', Blue |
CAT5E Cable |
K5E-1KUTP-WH |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Solid, 1000', White |
CAT5E Cable |
K5E-1KUTP-YL |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Solid, 1000', Yellow |
CAT5E Cable |
K5E-1KUTP-RD |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Solid, 1000', Red |
CAT5E Cable |
K5E-1KUTP-BK |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Solid, 1000', Black |
CAT5E Cable |
K5E-1KUTP-GR |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Solid, 1000', Green |
CAT5E Cable |
K5E-1KUTP-GY |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Solid, 1000', Gray |
CAT5E Cable |
K5E-1KUTP-BL/ST |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Stranded, 1000', Blue |
CAT5E Cable |
K5E-1KUTP-GR/ST |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Stranded, 1000', Green |
CAT5E Cable |
K5E-1KUTP-OR/ST |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Stranded, 1000', Orange |
CAT5E Cable |
K5E-1KUTP-RD/ST |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Stranded, 1000', Red |
CAT5E Cable |
K5E-1KUTP-WH/ST |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Stranded, 1000', White |
CAT5E Cable |
K5E-1KUTP-YL/ST |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Stranded, 1000', Yellow |
CAT5E Cable |
K5E-1KUTP-GY/ST |
CAT-5E 350MHz Cable, 24AWG, UTP, 4 Pairs, Stranded, 1000', Gray |
CAT5E Cable |
K5E-1KSTP-RD |
CAT-5E 350MHz Cable, 24AWG, STP, 4 Pairs, Solid, Shielded, 1000', Red |
CAT5E Cable |
K5E-1KSTP-YL |
CAT-5E 350MHz Cable, 24AWG, STP, 4 Pairs, Solid, Shielded, 1000', Yellow |
CAT5E Cable |
K5E-1KSTP-BL |
CAT-5E 350MHz Cable, 24AWG, STP, 4 Pairs, Solid, Shielded, 1000', Blue |
CAT5E Cable |
K5E-1KSTP-GR |
CAT-5E 350MHz Cable, 24AWG, STP, 4 Pairs, Solid, Shielded, 1000', Green |
CAT5E Cable |
K5E-1KSTP-BK |
CAT-5E 350MHz Cable, 24AWG, STP, 4 Pairs, Solid, Shielded, 1000', Black |
CAT5ECable |
K5E-1KUTP-CMX |
CAT-5E 350MHz, Cable, 24AWG, UTP, 4 Pairs, Solid, 1000', UV Jacket for Outdoor Use, (CMX) Cable, Black |
CAT5E Cable |
K5E-1KUTP-CMXF |
CAT-5E 350MHz, Cable, 24AWG, UTP, 4 Pairs, Solid, 1000', Outdoor Aerial/Duct Cable, Flooded Core, Direct Burial, FRPE Jacket, (CMX) Cable, Pull Box, Black |
CAT5E Cable |
K5E-1KUTP-CMXT |
CAT-5E 350MHz, Cable, 24AWG, UTP, 4 Pairs, Solid, 1000', Outdoor Aerial/Duct Cable, Mylar Foil & Water Proof Tape, FRPE Jacket, Direct Burial, (CMX) Cable, Pull Box, Black |
|
Category 6 (CAT 6) technology is rapidly growing in the telecommunications industry’s commercial market. CAT 6 has been under development since late 1997. Originally, the wiring was intended to go from the 100 MHz capability of CAT 5 to 200 MHz, but later that was revised to 250 MHz. CAT 6 provides for other metrics as well, variables that become important at high bandwidth rates. These include crosstalk, or interference between wire pairs, and skew, the difference in timing of signals on the wires.
American
Data Supply Will Custom Cut Your OSP CAT 5e or CAT 6 Cable and
Connectorize Your Outside Plant Cable- and SHIP IT THE SAME DAY!
( for an additional cost)
Why Go CAT 6 Cable? Click
American Data Supply Carries thousands of types of cables from the below manufacturers for CAT 5e cable, CAT 5e Plenum, CAT 6 plenum, CAT 6 cable and Outdoor Rated CAT 5e Cable
Outdoor
Rated CAT 5e and CAT 6 Patch Cords
OUTDOOR
Rated CAT 5e
CABLE
& Patch Cords CAT 5e Outdoor
Cable: Part # American Data Supply 763108 CAT 5e Outdoor Cable-1000' Outdoor
Rated Category 5e Heavy Duty Industrial Grade Ethernet Cable -
Sunlight/UV/Oil Resistant Jacket Suitable for Burial - Unshielded
with Unbonded Pairs - Black Coat, PC Connection's Enhanced Category
5e Flooded Outdoor Ethernet cable is made from 4-pair, 24AWG solid
copper wire, enclosed in an outdoor rated, moisture and chemical
resistant black polyethylene jacket. Flooding compound surrounds
the twisted pairs, providing additional moisture protection. This
cable is engineered to meet or exceed ANSI/TIA/EIA 568-B.2 performance
criteria for 10/100/1000BaseT Ethernet applications-Extreme
outdoor gel filled, UV rated, plenum, Cat 5e cable. Perfect for
extreme weather conditions. Can be ran exposed or buried.
American Data Supply
763108 CAT 5e Outdoor Cable-1000' Outdoor Rated
Category 5e Heavy Duty Industrial Grade Ethernet Cable - Sunlight/UV/Oil
Resistant Jacket Suitable for Burial - Unshielded with Unbonded
Pairs - Black Coat, PC Connection's Enhanced Category 5e Flooded
Outdoor Ethernet cable is made from 4-pair, 24AWG solid copper
wire, enclosed in an outdoor rated, moisture and chemical resistant
black polyethylene jacket. Flooding compound surrounds the twisted
pairs, providing additional moisture protection. This cable is
engineered to meet or exceed ANSI/TIA/EIA 568-B.2 performance
criteria for 10/100/1000BaseT Ethernet applications-Extreme
outdoor gel filled, UV rated, plenum, Cat 5e cable. Perfect for
extreme weather conditions. Can be ran exposed or buried.
American Data Supply
765108 CAT 6 Outdoor Cable-1000' Outdoor Rated CAT 6-
Category 6-Heavy Duty Industrial Grade Ethernet Cable - Sunlight/UV/Oil
Resistant Jacket Suitable for Burial - Unshielded with Unbonded
Pairs - Black Coat, PC Connection's Enhanced Category 5e Flooded
Outdoor Ethernet cable is made from 4-pair, 24AWG solid copper
wire, enclosed in an outdoor rated, moisture and chemical resistant
black polyethylene jacket. Flooding compound surrounds the twisted
pairs, providing additional moisture protection. This cable is
engineered to meet or exceed ANSI/TIA/EIA 568-B.2 performance
criteria for 10/100/1000BaseT Ethernet applications-Extreme
outdoor gel filled, UV rated, plenum, Cat 6e cable. Perfect for
extreme weather conditions. Can be ran exposed or buried. THIS
IS CATEGORY 6 -CAT 6 Outdoor cable.
Part
# 765108 CAT 6 Outdoor Cable Spec's- Outdoor
Cat 6 pdf
Our
American Data Supply 763108 CAT 5e Outoor Cable: ListPrice:
$ 310/1000 feet, Our Price $ 189.99/1000
Feet- Discount Available!!Call (866) 342-3721
Our American Data Supply 763108 CAT 5e Outoor Cable-1000' Outdoor Rated Category 5e Heavy Duty Industrial Grade Ethernet Cable is not the same as you can buy at 'retails stores that is rated as "indoor-outdoor'- this is the real mccoy and can be direct buried into the ground.
Order Part Number:
American Data Supply
763108 CAT 5e Outoor Cable (Custom Lengths Available!-
American Data Supply will cut, and terminate your CAT 5e Outdoor Rated Cable- SAME
DAY SHIPPINg available for additional cost.
American Data Supply 763208 Aluminum Shielded Cable (Call For Minimum Order) -Aluminuml Shielded Cable (Call For Minimum rder)-1000FT OSP Broadband Cat5e Steel Shielded Cable - 4 pair-Category 5e OSP cables are designed to provide extension of the LAN beyond the premises. AluminumShielded for protection against EMI/RFI. A variety of constructions are available to suit multiple environmental needs.
American Data Supply 763308 Steel Shielded Cable (Call For Minimum Order)-1000FT OSP Broadband Cat5e Steel Shielded Cable - 4 pair-Category 5e OSP cables are designed to provide extension of the LAN beyond the premises. Steel Shielded for protection against EMI/RFI. A variety of constructions are available to suit multiple environmental needs.The ultimate in OSP rated CAT 5e cable.
SPECIFICATIONS
ACR (Minimum)—Typical: 30.5 dB/100 m (328.1 ft.) at 100 MHz
Attenuation (Maximum)—22 dB/100 m (328.1 ft.) at 100 MHz
Conductor—24 AWG, solid, insulated copper
Insulation—HD-polyethylene;
Nominal diameter: Standard: 0.23", (0.58 cm); Armored: 0.34" (0.86 cm)
Jacket—UV-resistant, abrasion-resistant polyethylene
NEXT (Minimum)—Typical: 51.7 dB/100 m (328.1 ft.) at 100 MHz
PS-NEXT (Minimum)—Typical: 44.8 dB/100 m (328.1 ft.) at 100 MHz
Return Loss (Minimum)—Typical: 21.2 dB/100 m (328.1 ft.) at 100 Hz
Time Delay Skew (Maximum)—25 nanoseconds
Temperature— -94° to +167° F (-70° to +75° C)
American Data Supply also offers wholesale priced CAT 5e Cable via "pallet purchasing" in 1000 foot reels for less than $40.00 per box. Plenum CAT 5e plenum at pallet pricing is from $ 70-$85.00 per 1000 foot reel.Please call for details at (866) 650-DATA.
Dielectric Cables Outdoor OSP Cables
Military Cables
Security Cables
Indoor- Outdoor Cables
Datacom/Central Office Cables
UltraPipe
UltraPipe Category 6e+ cables exceed all proposed Category 6 specifications and provides superior bandwidth performance up to 550Mhz to support broadband video and high-speed full-duplex transmission protocols. It defines a new level of performance with a 300% improvement in PowerSum Crosstalk and a 60% improvement in return loss over Category 6. UltraPipe's patented design includes the revolutionary Isolator pair separator, which resolves NEXT and ELFEXT issues required for accurate transmission using all four pairs.
6ECMP 4 pair non 3x1
6ECMR
4 pair non-plenum
6EJCM
4 pair patch cord
UltraMedia Cable
Engineered specifically for high-speed, full-duplex, parallel transmission protocols that dominate new technologies, UltraMedia's patented design, which includes the revolutionary Isolator pair separator, resolves ELFEXT and balance issues required for accurate transmission using all four pairs. Specified to 400Mhz, UltraMedia provides the performance margin against Category 6 requirements necessary for bandwidth intensive applications such as 3D imaging and Gigabit Ethernet.
7504
4 pair plenum
75N4
4 pair non-plenum
6NF4
4 pair outdoor
Media
6
The Commscope Media 6 meets all Category 6 specification to support broadband video and high speed, full-duplex transmission protocols that new technologies demand. Features include a flexible jacket, thousand to zero footage markers, vibrant colored pairs with a co-extruded color stripe for easy identification, and a smaller OD than typical Category 6 products
4 pair plenum
Residential
Cabling Products
When it comes to residential cabling, look to CommScope to provide the solution. Our UltraHome® cables meet the needs of voice, data, and video applications in one easy-to-install product. The UltraHome family consists of coaxial cable, Category 5e unshielded twisted pair, and multimode fiber in single, Siamese, and bundled configurations designed for delivering true multimedia inside the home.
Recently,
CommScope introduced their expanded Residential Cabling line.
The Residential Cabling catalog contains 20 new coaxial, fiber,
and UTP cables for residential voice, data, and video applications
in single, Siamese, and bundled designs. CommScope's UltraHome®
residential cabling products provide the foundation to support
the capabilities of today's technology as well as those of the
future.
DRAKA-
Helix -Hi Temp Products
Category 6 UTP (SuperCAT1000)
plenum (805508), non-plenum (705508) and patch cables (705708)
with 200 MHz bandwidth that deliver 2.4 GHz performance
Enhanced Category 5e UTP (SuperCAT360) plenum (804508), non-plenum
(704508) and patch cables (704708) tested to 360 MHz for extended
Category 5e performance
Category 5e UTP (SuperCAT100E) plenum (803308), non-plenum
(703408) and patch cables (701308) that meet all Category 5e
performance criteria
Category 5e UTP for outdoor applications (All Weather SuperCAT)
for direct buried, duct or aerial applications (763108) when
Cat5e performance is needed to withstand weather or temperature
extremes - aluminum armored (763208) and steel armored (763308)
versions available
Category 5 (SuperCAT100) plenum (803508), non-plenum (703108)
and patch cables (701008) delivering solid 100 MHz Category
5 performance - 25 pair versions are available in plenum (803150)
and non-plenum (703150) constructions
Category 3 UTP - plenum (801308), non-plenum (702308) and patch
cables (700708) available - 25 pair versions are available in
plenum (801350) and non-plenum (702350) constructions - patch
cables available in 2, 3 and 4 pair
Local Area Network Products - Category 5e+
5504M 4 pair plenum 3x1
5504 4 pair plenum 4x0
55N4R 4 pair non-plenum
5524M 8 pair plenum 3x1
5N54 8 pair non-plenum
5NF4 4 pair outdoor
OUTSIDE RATED CAT 5e CABLE
This all weather SuperCAT cable is an outdoor rated CAT 5e cable that can be installed directly in the ground, inside a duct or aerially lashed to a support member. The cable is fully flooded and has a tough UV and abrasion resistant black polyethlene jacket. The cable is designed to withstand temperatures as low as -70degrees C (Celsius) and as high as 75 degress C. Data transmission rates are up to 100Ms/second. This cable is the ideal solution for connecting LAN terminal locations outside the main building such as portable classrooms without the need to use expensive optical fiber systems.Optional aluminum or steel shielding systems provide addtional protection for EMI and damage caused by rodents.
Order
Part Number:
American Data Supply 763108
CAT 5e Outoor Cable (Custom Lengths Available!)
American Data Supply 763208
Aluminum Shielded Cable (Call For Minimum Order)
American Data Supply 763308
Steel Shielded Cable (Call For Minimum Order)
|
