 Multimode Fiber Optic Splice Kit
P/N CS001200
Singlemode Fiber Optic Splice Kit
P/N CS001201 |
The FAST connector tool kit provides all the necessary installation tools required for fiber preparation of 250um or 900um fibers applied to AFL’s new pre-polished FAST connectors. Included in the kit options are the selection of either a multimode cleaver (92208-TB) with a proven 25 year field-use history or the new Universal multimode/single-mode cleaver (CT-30A), AFL’s premier cleaver with a 16 position blade and built-in fiber scrap collector. The tool kit effectively contains all the industry standard termination tools and still permits an adequate storage area for extra FAST connectors for on-site convenience. |
Multimode Fiber Optic Splice Termniation Kit
P/N CS001200
Singlemode/Multimode Fiber Optic Splice Termniation Kit
P/N CS001201
|
 |
92208-TB Multimode Cleaver
(Included in CS001200 Tool Kit) |
Features:
| • |
Singlemode fiber precision |
| • |
Suitable for fast, in-field terminations |
| • |
Proven field reliability |
| • |
Eliminates polishing |
• |
No special training required
|
• |
Repeatable: < 1 degree angle typical |
|
 |
CT-30A Universal Cleaver
(Included in CS001201 Tool Kit) |
The CT-30 Cleaver sets the standard for portable, reliable and ease of use. Available for either single fiber or ribbon splicing (up to 12 fiber ribbons) applications, the CT-30 Cleavers are compatible with all AFL Telecommunications fusion splicers. Designed for excellent portability, the CT-30 is equally at home in a splicing van or in a bucket truck and is ideal for FTTx applications. |
 |
The Field Master Tool Kit includes tools and consumables to professionally install Field Master connectors. Crimp Tool sold separately.
More Info -Field Master® Tool Kit FM000065 |
More Info- Part Number Field Master® Tool Kit FM000065 |
 |
Crimp Tool with Die Set (SC, ST, & LC)
(Crimp diameters: .151” hex, .178” hex, .213” hex)
More Info- Part Number |
More Info- Part Number |
AFL Fast Field Termination Connectors:
Features:
| • |
Easy assembly process |
• |
Fiber can be reseated
|
• |
No expensive tools required
|
• |
No epoxy required |
• |
Factory polishing eliminates loss concerns |
• |
Meets TIA/EIA 568A performance requirements |
|
|
FAST Connectors feature a pre-stubbed factory-polished ferrule that couples to the fiber being terminated by precision mechanical alignment, insuring low loss with a proprietary gel. Each FAST Connector comes with a factory-installed wedge clip that holds the clamping device open while the fiber is inserted. Once the fiber is in place, the wedge clip is removed and discarded.
AFL’s new FAST Connectors are pre-polished, field installable connectors that eliminate the need for hand polishing in the field. FAST Connectors provide an immediate termination to either single-mode or multimode fibers. |
AFL’s new FAST Connectors are pre-polished, field installable connectors that eliminate the need for hand polishing in the field. FAST Connectors provide an immediate termination to either single-mode or multimode fibers.
Applications:
| • |
Premise environments |
• |
Connections at the desk for LAN environments |
• |
Patch panels |
• |
Direct equipment termination |
• |
Fiber to the Subscriber (FTTx) applications |
• |
Repair/replacement requirements |
|
 AFL SC, ST and LC Connectors
|
The Field Master™ Connectors for field termination of fiber optics feature high precision, high reliability and low applied connector cost. Durable metal components, industry-standard connector designs, and proven crimp technology gives the customer peace-of-mind that their installed network is steady and reliable. |
The Field Master™ Connectors for field termination of fiber optics feature high precision, high reliability and low applied connector cost. Durable metal components, industry-standard connector designs, and proven crimp technology give the customer peace-of-mind that their installed network is steady and reliable. Field Master™ Tool Kits come complete with all necessary tools and consumables for the professional installation of AFL’s Field Master™ Connectors. |
Precision Connectors |
Custom drilled hole sizes are produced very precisely in the metal ferrules of industry standard connectors such as the SMA, ST, and FC. A range of sizes from 140 micron to 1235 microns are typical, but customer specific sizes are possible. Stainless steel or steel alloy (Arcap) are available depending on the customer’s requirement. |
|
 |
The AFL Optical Data Link combines the benefits of fiber optic signaling with the convenience of plug-in PCB electrical termination. It is designed to permit fast, reliable, self-termination of single channel plastic optical fiber without the needs of special tools, adhesives or polishing. |
Features:
| • |
Terminates plastic fiber optic cable in seconds without tools, adhesives or polishing |
• |
Compatible with 1000µm diameter simplex fiber with an OD of 2.25mm or 5mm |
• |
Polarized plug provides positive, snap retention with a quick-release latch |
• |
No epoxy required |
• |
Factory polishing eliminates loss concerns |
• |
Meets TIA/EIA 568A performance requirements |
|
